What is the impedance of the RD1415-01 speaker driver?

The RD1415-01 has an impedance of 32 ohms ±15% at 1kHz with a 1mW input.

What is the maximum power handling of the RD1415-01?

The driver can handle up to 10mW of power as its short-term maximum.

What materials are used in the diaphragm of the RD1415-01?

The diaphragm is made of a composite of PEEK and PU for durability and acoustic performance.

What is the SPL rating of the RD1415-01?

It delivers 126 ±3dB SPL at 1kHz with 179mVrms input using 711EAR standards.

Is the RD1415-01 suitable for high-reliability applications?

Yes, the RD1415-01 has passed tests for humidity, temperature, vibration, salt spray, and tensile strength, making it suitable for demanding environments.

RD1415-01 | 14mm Dynamic Earphone Speaker Driver | 32Ω 5mW

<--

-->

Designed By: SpeakerDriver
Product ID: RD1415-01

RD1415-01 | 14mm Dynamic Earphone Speaker Driver | 32Ω 5mW | 126dB SPL

The RD1415-01 is a high-performance 14mm dynamic speaker driver designed for earphones. Featuring 32Ω impedance and a rated power of 5mW (max 10mW), it achieves an impressive SPL of 126±3dB. Built with a PEEK+PU composite diaphragm, NdFeB magnet, and rugged SPCC frame, it offers excellent durability and sound quality. It withstands extensive reliability tests, including temperature, humidity, vibration, and salt spray.

Size
14mm

Price
0$

MOQ
3000 Units

Leadtime
25 days

Technical
Specifications

RD1415-01 Speaker Driver Specifications
Driver Size	14mm
Impedance	32Ω ±15%
Rated Power	5mW
Max Power	10mW
SPL (1kHz, 179mVrms)	126 ±3dB
Frequency Response	20Hz – 8kHz
Resonance Frequency	220 ±20% Hz
THD	≤2.8% @ 1mW
Diaphragm Material	PEEK + PU Composite
Magnet Type	NdFeB
Net Weight	Approx. 1.3g
Operating Temp Range	-20°C to +65°C
Storage Temp Range	-20°C to +65°C
Test Standard	711EAR, 179mVrms Input
